Line-up

1. X-mas Tree
2. eruption manifold
3. rock-catcher
4. Choke-manifold
5. separator
6. Sealine

Equipments

1. X-mas Tree
   • Swap is open
   • M/V is open
   • W/V is open
   • DHSV is open
2. eruption manifold
   • lined up from the well to the rock-catcher
3. rock-catcher
   • we can flow through the filter/ strainer or we can bypass it
4. Choke-manifold
   • we can use adjustsble side (if we are using for a short time) or fixed side (if we are using for a short time) _{the test takes four hours for each choke size}
5. separator
   we can bypass separator or we can flow through it
   • Oil Line:-
     • oil line is open
     • Setting LCV
     • Checking flow meter
   • Oil Line:-
     • Gas line is open
     • Setting PCV
     • Checking separator pressure
     • once we runing the orifice plate and closing the equalizer of the differential sesnor (DPU) we monitor Diff. Press.
6. Sealine
   • sealine diverter valve is open
   • sealine valve is open

Operation

1. Samples:-
   • BS&W (Water Cut)
   • API & Temp.
   • H₂S & CO₂
   • shrinkage
   • Gas SG
2. Gas Line
   • Setting PCV
   • Monitoring Separator pressure
   • After Stabilizing the level we can run the orifice plate to start flow test
3. Oil Line
   • Setting the LCV
   • Monitoring Separator Level
   • Monitoring Flow meter
4. Monitoring
   • WHP
   • WHT
   • DSP
   • SEP.P.
   • SEP.T
   • SLP
   • SEP. Level
   • Annulus (A)
   • Diff. Press.
   • Flow meter
   • Delta Press. for the rock-catcher

Notes

• Set the adjustable choke size before opening the choke
• increasing the adjustable choke size gradually
• always open downstream valve before upstream one
• opening upstream chokemanifold valve slowly to avoid hydration and going down WHP suddenly
